    CSK P and CSK PP
CSK P CSK PP

Bearing No. Size(mm) Load Rating Weight Friction
Resistance
d D L TKN1)
(Nm)		 nmax
(min-1)		 C
(KN)		 CO
(KN)		 (kg) TR(Nom)
CSK6202 P 15 35 11 13.5 8400 7.4 3.42 0.06 0
CSK6203 P 17 40 12 24.5 7350 7.9 3.8 0.07 1.1
CSK6204 P 20 47 14 40 6000 9.4 4.46 0.11 1.3
CSK6205 P 25 52 15 68 5200 10.7 5.46 0.14 2
CSK6206 P 30 62 16 110 4200 11.7 6.45 0.21 4.4
CSK6207 P 35 72 17 140 3600 12.6 7.28 0.3 5.8
CSK40 P 40 80 22 260 3000 15.54 12.25 0.5 7
CSK6302 P 15 42 13 24.5 7350 7.9 3.8 0.07 1.1
CSK6303 P 17 47 14 40 6000 9.4 4.46 0.11 1.3
CSK6304 P 20 52 15 68 5200 10.7 5.46 0.14 2
CSK6305 P 25 62 17 110 4200 11.7 6.45 0.21 4.4
CSK6306 P 30 72 19 140 3600 12.6 7.28 0.3 5.8
CSK6307 P 35 80 21 260 3000 15.54 12.25 0.5 7
CSK40* P 40 90 23 400 2400 16.53 15.38 0.82 9.2
CSK6202 PP 15 35 11 13.5 8400 7.4 3.42 0.06 0.9
CSK6203 PP 17 40 12 24.5 7350 7.9 3.8 0.07 1.1
CSK6204 PP 20 47 14 40 6000 9.4 4.46 0.11 1.3
CSK6205 PP 25 52 15 68 5200 10.7 5.46 0.14 2
CSK6206 PP 30 62 16 110 4200 11.7 6.45 0.21 4.4
CSK6207 PP 35 72 17 140 3600 12.6 7.28 0.3 5.8
CSK40 PP 40 80 22 260 3000 15.54 12.25 0.5 7
CSK6302PP 15 42 13 13.5 7350 7.9 3.8 0.07 1.1
CSK6303PP 17 47 14 24.5 6000 9.4 4.46 0.11 1.3
CSK6304PP 20 52 15 40 5200 10.7 5.46 0.14 2
CSK6305PP 25 62 17 68 4200 11.7 6.45 0.21 4.4
CSK6306PP 30 72 19 110 3600 12.6 7.28 0.3 5.8
CSK6307PP 35 80 21 140 3000 15.54 12.25 0.5 7
CSK40*PP 40 90 23 260 2400 16.53 15.38 0.52 9.2
