| Pillow Block Bearings-UCPW200 Series |
|
|
 |
 |
| |
| BearingUint
No. |
Shaft
Dia d |
Dimensinons(mm) |
Bolt
Used |
Bearing
No. |
Housing
No. |
Housing
Wt(kg) |
| h |
a |
e |
b |
t |
r |
g |
w |
Bi |
n |
(mm) |
| (in) |
(mm) |
| UCPW201-8 |
1/2 |
|
33.3 |
65 |
50.8 |
32 |
M8 |
13 |
13 |
65 |
31 |
12.7 |
M8x1.25 |
UC201-8 |
PW204 |
0.38 |
| UCPW202-9 |
9/16 |
|
UC202-9 |
| UCPW202-10 |
5/8 |
|
UC202-10 |
| UCPW203-11 |
11/16 |
|
UC203-11 |
| UCPW204-12 |
3/4 |
|
UC204-12 |
| UCPW201 |
|
12 |
UC201 |
| UCPW202 |
|
15 |
UC202 |
| UCPW203 |
|
17 |
UC203 |
| UCPW204 |
|
20 |
UC204 |
| UCPW205-13 |
13/16 |
25 |
36.5 |
70 |
50.8 |
36 |
M10 |
13 |
13 |
70 |
34 |
14.3 |
M10x1.5 |
UC205-13 |
PW205 |
0.40 |
| UCPW205-14 |
7/8 |
UC205-14 |
| UCPW205-15 |
15/16 |
UC205-15 |
| UCPW205-16 |
1 |
UC205-16 |
| UCPW205 |
|
UC205 |
| UCPW206-17 |
1-1/16 |
30 |
42.9 |
98 |
76.2 |
38 |
M10 |
16 |
15 |
82 |
38.1 |
15.9 |
M10x1.5 |
UC206-17 |
PW206 |
0.85 |
| UCPW206-18 |
1-1/8 |
UC206-18 |
| UCPW206-19 |
1-3/16 |
UC206-19 |
| UCPW206-20 |
1-1/4 |
UC206-20 |
| UCPW206 |
|
UC206 |
| UCPW207-20 |
1-1/4 |
35 |
47.6 |
103 |
82.6 |
45 |
M10 |
19 |
15 |
93 |
42.9 |
17.5 |
M10x1.5 |
UC207-20 |
PW207 |
0.90 |
| UCPW207-21 |
1-5/16 |
UC207-21 |
| UCPW207-22 |
1-3/8 |
UC207-22 |
| UCPW207-23 |
1-7/16 |
UC207-23 |
| UCPW207 |
|
UC207 |
| UCPW208-24 |
1-1/2 |
40 |
49.2 |
116 |
88.9 |
47 |
M12 |
19 |
15 |
99 |
49.2 |
19.0 |
M12x1.75 |
UC208-24 |
PW208 |
1.25 |
| UCPW208-25 |
1-9/16 |
UC208-25 |
| UCPW208 |
|
UC208 |
| UCPW209-26 |
1-5/8 |
45 |
53.9 |
120 |
95.3 |
48 |
M12 |
19 |
18 |
107 |
49.2 |
19.0 |
M12x1.75 |
UC209-26 |
PW209 |
1.52 |
| UCPW209-27 |
1-11/16 |
UC209-27 |
| UCPW209-28 |
1-3/4 |
UC209-28 |
| UCPW209 |
|
UC209 |
| UCPW210-29 |
1-13/16 |
50 |
57.2 |
135 |
101.6 |
54 |
M16 |
22 |
18 |
115 |
51.6 |
19.0 |
M16x2 |
UC210-29 |
PW210 |
1.90 |
| UCPW210-30 |
1-7/8 |
UC210-30 |
| UCPW210-31 |
1-15/16 |
UC210-31 |
| UCPW210-32 |
2 |
UC210-32 |
| UCPW210 |
|
UC210 |
|
|
|
|
